SQL Server 2008 SP1 - Cannot drop database because it is currently in use.

Recently I came across an issue in SQL Server 2008 SP1 where I was trying to rebuild our DEV databases from script (we have Nant scripts that perform a continuous build process so we know that they work) but during the rebuild the process failed because one of the databases could not be dropped. At first I thought that there must be existing connections to the database but a quick review of the output of "sp_who2" showed no such thing.

Anyway, to shortcut the whole build process I figured I would just use SQL Server Management Studio to manually drop the database and enable the "force close existing connections" option. However, this too failed saying that the database was currently in use, even with the "force close" option set and even more bizarrely once again when I checked the output of "sp_who2", I could not see any connections to the particular database in question. Restarting the SQL Server service didn't help either.

A quick Google search on this error message produced quite a few hits (as you probably know if you found this page that way), a lot of which seemed to indicate that the way to resolve this is to alter the database into single user mode with the immediately rollback option set. Using this produced no joy for me either, which wasn't really surprising considering that there appeared to be no connections in the first place.

In the end, this is how I solved it… You need to get SQL Server to tell you who is blocking the drop command. Not rocket science is it, once you know the answer. ;-) So…

• First of all, using SQL Server Management Studio, open a query window on to the server and ensure that it is connected to the [master] database.
• Next, also using SQL Server Management Studio, right click on the database in question and select the option to drop the database and enable the "close existing connections" option. Click OK.
• While this is trying to drop the database, quickly switch to the open query window and run "sp_who2". Look through the result set for the row with a status of "SUSPENDED" and note the value in the "BlkBy" column.
• Also in the query window, execute the kill command to kill the spid with the value noted in the point above.

And there you go, the database will have been dropped as soon as you killed the SPID.

Wierd eh?

Analysis Services 2005 - Dynamic Default Member

Whilst migrating a database from AS2000 to AS2005 I came across in interesting issue when trying to replicate the same behaviour as the "legacy" version. Firstly, a little background...

For the sake of expediency I used the migration wizard to convert most of the AS2000 database over to AS2005. I say most because although the validation checker stated that everything was a-okay, when it came to actually do the migration the wizard whinged about a dimension that was joined to different cubes at different levels within the dimension. In order to progress this, I deleted the dimension and migrated the rest.

So, what I was left with was a pretty complete system that, although not overly complex, it wasn't trivial either. The database contained a number of cubes and virtual cubes etc. and they contained a financial line dimension making use of unary operators and custom MDX for specific members. When designing the AS2000 database originally, I specifically avoided calculated cells so there were none of those but it did contain quite a number of calculated members. I must say that I was actually quite impressed with the conversion process once it worked. Certainly the dimensions were migrated quite well, though it made a bit of a mess of migrating the "alternate hierarchy" dimensions. I'm also not a big fan of using linked measure groups etc. so I'll probably back those out into a series of cubes using multiple measure groups etc. but I digress.

Whilst going through all the dimensions, to compare the migrated version to the original version, I noticed that the [Currency] dimension had not been migrated to be the same as the original. The dynamic default member definition was missing and needed to be added back. Now, based on AS2000 functionality, the [Currency] dimension had the default member defined using the "Filter" function to filter the members of the dimension based on a "Default Flag" member property such that when the member property was "1" it identified the default member.

In AS2005 the preferred method is to use the "Exists" function and it performs a lot better than filtering. Indeed, there is also a known issue in AS2005/8 where use of the "Properties" function when specifying a default member causes heap corruption during processing so it should be avoided. Now the interesting bit, The currency dimension does not have an "all" level so I set the "IsAggregatable" property to false, changed the "Default Flag" attribute's "AttributeHierarchyEnabled" property to true, to change it from a member property to a true attribute and set about deploying and processing the revised dimension. All of that resulted in the following error:
Errors in the metadata manager. The 'Currency' attribute with IsAggregatable=false must not have any relationship to 'Default Flag' attribute that has AttributeHierarchyEnabled=true

So, rather interestingly, you cannot have attribute 'x' related to attribute 'y' if attribute 'y' has its "IsAggregatable" property set to false. Converting attribute 'x' to a member property serves to allow the dimension to deploy but prevents the use of the attribute in the "Exists" function. One would have to revert back to the use of the "Filter" function which we really need to avoid. Now I'm not sure why this limitation exists, it just does. So how to work around it?

Well what I did, was to create a copy of the key attribute and have it related to the key. I changed the attribute relationship to "Rigid", as this should never change, and the cardinality to "one to one" even though this latter property isn't used in AS2005. Then, on the key attribute, I set the "IsAggregatable" property to true, the "AttributeHierarchyVisible" property to false and left the "Default Flag" attribute relationship on the key. The key also had to be renamed so I added an underscore to the end of it.

On the copied attribute (i.e. the copy of the key) I renamed it to the name of the key attribute but without the underscore, set the "IsAggregatable" property to false and defined the default member with MDX using the "Exists" function and the "Default Flag" attribute as follows:
Exists([Currency].[Currency].[Currency].Members, [Currency].[Default Flag].&[1]).Item(0)

This appears to do the trick at the expense of duplicating the attribute, providing a dynamically set default member on an attribute that is not aggregatable.

I hope this helps others out there who may face the same issue and hey, if you know why you can't do this straight on the key, please enlighten me!

Installing Subversion from source on CentOS 5.2

Okay so this not strictly BI related but hey, most of us BI types have a slight geek inclination don't we, or is that just me?

I guess the main reason for blogging about this is that I really didn't expect this to be that hard. I mean, I've been installing Subversion from source since about Fedora Core 3 without issues (other than when the Subversion/Berkley DB integration underwent some changes that shafted access to my repositories) so I kinda expected the same here. Um, wrong! At least this time the issue related to a fresh install rather than suddenly finding that I can no longer access my repositories. Needless to say I now use FSFS rather than Berkley DB as the back-end but still. A friend of mine also works on FSFS (see: http://www.farside.org.uk/200704/tree_structured_fsfs) so he'd been going on at me for a while to switch. Still took that heartache to make me use FSFS though, groan...

Anyway, so a while back (meant to blog about this a long time ago but based on how long it has been since my last blog, I can see that it really was a loooong time ago) I set about compiling Subversion from source code. I guess there are many reasons for installing Subversion from source code but that's immaterial here. Needless to say that I started and soon came to realise after running ./configure that there were some missing dependencies when trying to enable SSL. After a little bit of searching and running rpm -qa etc. to find if certain libraries were installed I found that my install of CentOS was missing the openssl-devel library. So, a quick install using yum and I was away, or was I?

Okay, so maybe not. After installing the missing library another error occurred during the ./configure script run. This particular issue, however, is documented in the Subversion documentation and requires you to amend the parameters passed to the configure command in order to have the information passed through to the "sub-configure" scripts. Rather bizarrely you need to specify the --with-libs parameter, specifying "/usr/kerberos" as the value. (i.e. --with-libs=/usr/kerberos)

I guess the part that really got me for a while was the fact that when you run the configure script, passing in the above mentioned switch, a message is generated on the first line stating: "configure: WARNING: unrecognized options: --with-libs" however this message can be safely ignored. That little tidbit of information is not specified in the documentaion. So, if you leave the script to run it should actually run to completion, barring any other issues naturally.

Long and short of it is that in order to compile Subversion with SSL enabled on CentOS 5.2 (well with the my install base anyway) I had to do the following:

# Unpack the source
tar -zxvf subversion-<version>.tar.gz
cd subversion-<version>
# Check that openssl-devel has been installed.
yum list openssl-devel
# If not, install using the following:
yum install openssl-devel
# Configure and install subversion with FSFS,
# ignoring message "configure: WARNING:
# unrecognized options: --with-libs".
./configure --without-berkeley-db --with-ssl --with-libs=/usr/kerberos

And that's all there is to it!

Analytic Workspace Manager Locking

So, following on from my previous blog about plugins for the AWM, I thought I would provide a little information about something I learned whilst writing my own plugin.

Writing a plugin for the AWM and testing it can be cumbersome if you have to constantly start the AWM, login and then navigate to a node in the tree that allows you to activate your plugin. No, arguably a better way is to create your own testbed to simulate the AWM environment. That way you can run your code with less effort and interaction and are also afforded the ability to step through and debug your code if, like me, you need to.

In my case I merely created a Java class that effectively created an Oracle database connection and then called my plugin code, passing in the connection and anything else that it required. This was all fine and dandy whilst developing the code and afforded me the luxury of being able to test my code with the minimum of effort. However, when I eventually placed my code into the plugin framework (which to be fair I was doing simultaneously anyway) my code, well, didn't really stop working but rather, well... just seemed to stall.

This was masked by the fact that I was using multiple threads and thus parts of the plugin, though still functioning, arguably produced incorrect results. After a little investigation (okay, okay, so more than a little and certainly more than I would have liked) I discovered the reason...

There appears to be no fine-grained locking in Oracle OLAP, certainly as far as the AWM is concerned.

So what do I mean by that? Well, just that it is geared towards a single developer updating a given analytic workspace. Multiple updates to different parts of the workspace simultaneously are not supported nor, as far as I can tell, even possible.

So what does that mean to us? Well, when the AWM connects to the analytic workspace it attaches it in "read/write" mode. This means that any plugin code can only affect the contents of that analytic workspace by using the connection provided to it when the plugin is invoked. Retrieving/creating a new connection using the data source made available in the Map object presented to the plugin means that any code executed over that connection is in fact in a different session. As such, any code intended to affect the same analytic workspace that was attached by the AWM session created when the analytic workspace was attached will be blocked and will not be able to make changes or even process any objects in that analytic workspace.

At first I thought that that was it, game over but there is a "trick". This "trick", albeit a bit of hack and one not to be taken lightly, involves the use of the DBMS_AW package . More specifically, the use of the DETACH, UPDATE and ATTACH sub-programs allowing us to detach the analytic workspace over the main connection provided by the AWM to the plugin code. We can then "re-attach" it on the new connection in read-only mode (or read/write if you want) and perform whatever actions you would like on the given analytic workspace. The UPDATE sub-program is required in order to commit any changes that have already been made to the analytic workspace whilst it was in read/write mode prior to detaching it.

Note that there is a potential issue here. Detaching the analytic workspace and re-attaching it introduces the risk that in the meantime another session locks the workspace before the plugin secures it for its own use. Also, failure to ensure that the analytic workspace is attached in read/write mode before the plugin exits breaks the environment in which the AWM expects to function. (i.e. The AWM still "thinks" that the workspace is attached in read/write mode and will allow a user to try to make changes even though this may not be the case.)

Clearly the functionality that this provides needs to be weighed in conjunction with the expected working environment and the associated risks. If the environment is inherently single-user then no harm is done. However, if there is a multi-user environment where multiple people are likely to request read/write locks on the same analytic workspace, well, then your mileage may vary. Clearly you may be able to use transactions to mitigate some, if not all, of these risks but that remains to be seen.

As mentioned previously, oh how nice it would have been to be able to lock a specific dimension or cube etc. which, based on the metadata stored in the database, appears quite possible but just not implemented. This could have opened up opportunities for multi-user development environments to allow teamed development, maintenance and testing etc. What a novel concept, though sorely lacking here...

Analytic Workspace Manager Plugin Best Practices

The Analytic Workspace Manager (or AWM for short) is the tool to use when wanting to quickly create OLAP structures in the Oracle OLAP engine embedded within the Oracle relational database. Clearly you can use OWB etc. but AWM provides a lightweight easy to use interface for creating quick demos, restructuring content or processing etc. However, what the AWM provides may well not be everything to everyone and thus it is possible to create your own plugins, using Java, to get it to do what you want.

The documentation around doing this, I found, is a little light on the ground so to speak. So I have tried to document my findings here to help those that may wish to follow suit. However, before I start I should probably point out that in no way is the following post endorsed by Oracle. These are merely my observations after coding my own plugin for the Analytic Workspace Manager.

So here goes...
Step one is to find the Developing_AWM_Plugins_11g.pdf document. When I started coding my plugin for the 11g version of AWM, I could only find the 10g document which is not quite accurate for 11g. The OLAP API has changed somewhat in 11g and this is reflected in the OLAP API interface between the AWM and user plugin code. Looking at the document, I guess the pertinent points are that the 11g version of AWM requires the plugin to be compiled with Java 5 SE. (Or version 1.5 in "old school", just why did Sun confuse matters?) We'll come back to this but suffice to say that you'll need to remember that Java 5 brings with it support for generics.

Also in the document, if you have coded for 10g plugins, you may notice that the interface method signatures have changed a little. The AW object passed into the handle method is now an oracle.AWXML.AW object. The params parameter to the handle method provides a map, where the DATAPROVIDER key provides the ability to get a connection to the underlying Oracle database without requiring username/password information.

Step two, and arguably the most important step, is the understanding that on startup the Analytic Workspace Manager loads all Java code in the plugin directory and looks for any class files that implement the AWMPlugin interface. This is also documented in the above mentioned document, however, what is not made clear is that there will naturally be a performance impact on the startup time of AWM, the more classes and JAR files that you add to the plugin directory. Also, if you use 3rd-party JAR files you are at the mercy of those maintainers.

For example, placing the "jfreechart" JAR files in the plugin directory causes exceptions to be thrown in the AWM command window regarding missing Eclipse files. (I'm guessing that "jfreechart" is coded using Eclipse and some code dependencies are left behind.) Allowing this to happen with a user-defined plugin is pretty inelegant at best but most likely just down-right rude. We should avoid that, and we can.

The best practice I have come up with is as follows:

• The interface between the AWM and your plugin should reside in its own JAR file and only contain the minimum number of class files etc. in order to start the actual plugin. This keeps the startup time for the AWM to the minimum.

• The actual plugin code should be packaged into its own JAR file and placed elsewhere in the file system. (I use a subdirectory of the plugin directory so that it can be found using relative paths from the plugin interface.)
• Associated plugin dependencies should also be placed into a subdirectory (I use the same one as my own code as mentioned above) of the plugin directory.


Now, Oracle kindly provide a directory from which plugins can be found and executed but this clearly isn't scalable from a startup point of view if you require the use of large dependencies or lots of plugins. Oracle unfortunately don't provide the equivalent of an "Ext" directory into which dependencies could be placed. So here's the dilemma... Do we customise the Windows batch file (or *nix shell script) to include our dependencies in the classpath, or do we place our dependencies in one of the directories that is already referenced by the Oracle prescribed classpath?

My answer... neither! Customising the startup script is prone to failure if Oracle ever decide to update it. It also means deploying the plugin is a pain, in that everyone's installation may be different so deploying the script needs to take that into consideration. Hijacking the Oracle directories is also pretty "rude" and prone to cause issues down the line, not to mention taking into consideration once again the uniqueness of each installation. No, best practice would be to customise a URLClassLoader in order to dynamically load the dependencies at runtime and start the plugin. This unfortunately requires the use of reflection and is a bit more long winded but it will be far more robust and stand you in good stead during further developments.

My plugin used both "log4j" and "jfreechart", both of which had to be loaded onto the classpath with "log4j" needing to be instantiated in order to log progress. I may blog more on this in detail in the future, as doing this can be tricky and I couldn't find a definitive guide on this on the web.

Finally, coming back to generics, note that the AWMPlugin interface needs to be backwards compatible and as such does not make use of generics. This tends to generates compiler warnings. The way I would recommend handling this is to annotate the interface methods with "@SuppressWarnings("unchecked")" to suppress those warnings but only on the methods provided by Oracle. If you need to assign one of the variables found in the interface parameter list to to your own variable, you can use the generic wildcard, such as declaring "Map<?>", indicating the supertype.

And that's all there is to it.

Analysis Services 2005/2008 Heap Corruption

Recently I have been working for a financial institution who are using Analysis Service 2005 for their ad-hoc analysis. This particular client was experiencing issues with one of the Analysis Services servers producing memory mini-dump files during processing and causing service crashes and stalls whilst other servers were performing acceptably well.

The analysis of this issue started towards the end of 2007 and the reason for this has only now been diagnosed with the able help of Microsoft support. The particular system setup for this client is quite complex, using Oracle 10gR2 as the back-end relational database using flashback for referential integrity and consistency, the 11g (11.1.0.6.0) 64 bit OLE DB driver for connectivity from AS to Oracle and SSIS for scheduled processing. The AS database also makes extensive use of linked measure groups in order to provide a single cube of data with mixed granularity.

In order to diagnose the cause of the heap corruption we had to jump through quite a series of hoops. We initially went down the route of sending the mini-dump files to Microsoft for analysis but these naturally only provided limited and static information. Sending full dump files proved very tricky in the short term as the information that the cubes contain is confidential and cannot be sent off-site. In the end, restarting AS and only processing the dimensions and cubes (i.e. no queries being sent to AS) proved adequate to be able to send the full memory dump files off-site, as it would be extremely hard to put this in-memory information together in any meaningful way.

Still, the full dump files are also static and thus proved inconclusive. It could be seen from the dump files that heap corruption was indeed occuring during processing and there always appeared to be an Oracle error in the dump file as well. It seemed logical that the Oracle 11g driver could be the cause, as most clients tend to use the 10.2.0.3.0 Oracle OLE DB driver when connecting to Oracle 10.2.0.3.0 or later. In order to try and eliminate the 11g driver as the cause, we backed out the 11g driver and installed the 10.2.0.3.0 driver. (Note that in true Oracle fashion, this proved to be an exercise in and of itself. There is no Oracle 10.2.0.3.0 64 bit client installation. Noooooooo, that's waaaaay too easy! You have to install 10.2.0.1.0 and then patch it to 10.2.0.3.0. Oh, but wait, there is a patch before you apply the patch in order to get the patch to work etc. yadayadayada.) Anyhoo, I digress...

In the end, we found that using the Oracle 10.2.0.3.0 driver did not fix the problem. The next step then, was to divide and conquer so to speak...

Part one was to try and create a reduced test case by systematically removing complexity from the AS database. This was achieved by first removing the linked measure groups (I'm not aware of many people using this feature) and then to remove cubes and dimensions until a simple AS database could be created in which the issue could still be reproduced. The idea of this approach was to be able to get a small AS database with a tiny amount of non-confidential data so that Microsoft could perform in-house testing.

Part two was to use Time Travel Trace testing (TTT) which effectively allows one to debug the issue by being able to play forward and rewind the process over a given time span. This would allow one to see the changes made to the heap and replay them to identify the point at which the heap was corrupted. Rather amusingly though, there is a slight catch. This system was using AS2005 on Windows Server 2003 as are most installations I would suspect. However, TTT only works on Windows Server 2003 on a 32 bit architecture or Windows Server 2008 on a 64 bit architecture or if virtualised, only on Hyper-V.
Right, so a few changes to the test case then. As it happened we used a 32 bit environment and as luck would have it we were actually able to reproduce the issue, though TTT failed to work. Initially it exhibited the same symptoms as seen when used on Vista, where it "watched" the incorrect "thread" for activity. This should have been fixed be setting the processor affinity for AS. It wasn't...

As it happens, the TTT testing wasn't required. The reduced test case was effective and we were able to remove all confidential data. Microsoft took this in-house and managed to find the answer. So, are you ready for this? Do you want to know why memory heap corruption was occurring during processing? Well, do you?

Rather bizarrely, the reason for the heap corruption was the use of the ".Properties" function when specifying the default member in a dimension. Yup, the use of a specific function when specifying the default dimension member caused heap corruption during processing, not querying but processing. So how lucky am I that the reduced test case that I created used one of the only two dimensions out of 30 odd using that function when specifying the default member? Now I'm not sure why that function causes the issue and nor are the AS development team. They are still looking into it and from what I understand, were equally surprised. As it happens, the MDX that was being used to specify the default member wasn't particularly efficient in the first place (I must point out that it wasn't my code) and that once the code was changed to use the "Exists" function, it solved the problem.

Clearly your mileage may vary but nonetheless please be aware that the use of the ".Properties" function when specifying the default dimension member can cause heap corruption during processing. This is true for both AS2005 CU11 (or SP3 CU1) and AS2008 CU2. I'm still not sure why this only occurred on one of the servers when the other servers have the exact same database build but hey, removing the ".Properties" function solved the issue so clearly that was the problem.

You have been warned...

Is Oracle AWM 11.1.0.7.0A Better?

So, I'm about to present at a workshop tomorrow on Oracle 11g's Interval Partitioning and on the OLAP option and in preparation for the event I have had to create a demo. A while back I patched our 11.1.0.6.0 relational database to patch 8 but although both patch 10 and 11.1.0.7.0 have since been released, I decided not to risk upsetting things too much by installing those and have thus gone with the status quo. (Note that we have lots of Oracle software on that machine for demos and breaking things at any time is just not on!)

Incidentally, I just have to ask, does anyone actually know what each number in Oracle's version numbers stand for? I searched a while back but to no avail. But I digress...

Searching around on 11g versions and patches I came across an article that said that in order to patch the OLAP option you need to install either Patch 'A' or Patch 'B' but in order to patch the relational side of the engine you use the Patches 6, 8, 10 etc. Huh? When I installed patch 8 it had to back out patch 'A' (which is what the person who posted on the forum also found) so does that mean that the OLAP patches are mutually exclusive from the relational patches? That's a question I have yet to answer 'cos maybe you are meant to re-apply Patch 'A' after patch 8 etc. but that's a subject for a later post. (Especially since 11.1.0.7.0 has been released which appears to be for both relational and OLAP with patch #6890831. See the OLAP Certification page.)

Anyhoo, my big grumble with the Oracle Analytic Workspace Manager is that it seems to contain more bugs than an anthill. Seriously, does anyone actually test this thing? Within 2 minutes of using it I can get it to break. Lol, now I appreciate that my ineptitude is clearly a culprit in this issue in that if I did everything correctly it wouldn't break. However, exceptions are just that, exceptions and they need to be catered for.

Documentation seems to indicate that the preferred method of creating analytic workspaces etc. is to use Oracle Warehouse Builder and that the Analytic Workspace Manager is for "end users" who don't have access to the ETL/ELT process. It can also be used where OWB is not the ETL/ELT tool being employed.

Really? Whenever an exception is thrown I seem to get some Java exception ramblings about not being able to create a cursor or transaction or something equally inane. I'm sorry. It's coding like this that gives Java a bad name! Issues such as not being able to switch between a "star-schema" dimension and "snowflake" dimension after it has been built. Sure, you click on the drop down box and select it but sometimes the relevant member is selected but you don't get the correct representation in the mapping pane (i.e. visible/invisible "parent" member) or it just won't select.

Other irritations include:

• After defining a cube you can click on the cube name in the schema tree and even though the dimensions are greyed out, you can double click an available dimension and it will appear to be added to the cube's dimension list. It hasn't really, click off the cube and come back and the model is back as expected.
• Try creating a dimension over the "Sales Territory" dimension as available in the Microsoft AdventureWorks database and it will build. You can even browse it. However, join that dimension to a cube built off of the Internet Sales fact table and whoa... nasty exception.
• Why does the above nasty exception terminate my connection and cause random stuff to happen?
• How come building cubes off a database using the WE8MSWIN1252 characterset causes ORA-12704 characterset mismatch errors seemingly at random? Sometimes when I merely process something but always when trying to create cube organized materialized views. Sure I should be using UTF8 but the default for the "warehouse" database created by dbca is to use WE8MSWIN1252. What gives with that?

• ...

It is probably worth pointing out that the version of AWM that I was using was 11.1.0.7.0A and apparently that is expected to work against an 11.1.0.6.0 database. Maybe I should log these as bugs for Oracle to fix, I get that. My complaint though, is how did some of the issues I experience (maybe not listed here) even get through the door?

Does anyone on the development team actually use the product in a way that is not based on contrived samples? We all know that clinical test cases will work but what about the real world?

After all that, is the new version of AWM better? Yes. The fact that you can now create dimension levels at the time when you create a dimension (which I always thought was odd that you couldn't) is accepted with open arms. Despite all the ramblings above, it does seem a little more stable though that really isn't saying much. The default way of mapping columns to OLAP structures has changed from the graphical mapping view to the table mapping view which I think is for the better.

Bottom line, if you haven't switched yet, switch now. It's better for sure but don't expect an "Analysis Services development environment (i.e. BIDS)" type experience or you'll be sorely disappointed!

Hyperion EPM on Windows Server 2008

For an upcoming workshop we are running, covering the Oracle BI offering, I had to upgrade the relevant Oracle software to later versions. This included upgrading Oracle 11g to 11.1.0.6 patch 8 (11.1.0.7 not available for Windows at the time), upgrading Hyperion 9.3 to EPM Fusion edition and upgrading OBIEE plus. As an aside, the upgrade to Oracle 11g wasn't exactly seamless due to some Hyperion 9.3 service mainting a reference to the Oracle client dlls despite the fact that I had "uninstalled" Hyperion prior to the 11g patching. However, the use of ProcessExplorer soon highlighted the offending process and I was able to complete the patching in due course.

Installing Oracle/Hyperion Enterprise Performance Management Fusion Edition on Windows Server 2008 however, seemed to pose some interesting challenges. I'm not sure if this is as a result of running the Windows Server 2008 as the OS, the fact that the OS is actually running in Hyper-V, the fact that I uninstalled Hyperion 9.3 first and then installed EPM or something else but the net result was that it took me almost 2 days to solve an issue with OpenLDAP.

Attempts to start the Hyperion OpenLDAP service were unsuccessful and thus none of the other services were able to register with Shared Services. (i.e. The Shared Services service requires the OpenLDAP service to be up and running before it can start.) The failure to start the service provided little in the way of messages that would help debug the issue but consulting the EPM installation documentation (and Google) showed that you can start the OpenLDAP service from the command line using the "-d" switch in order to get some logging to sdtout. A switch of "-d 1" provides copious volumes of logging information and "-d -1" even more so. ;-)

Although this did produce some logging, in the end it was of little benefit as I got mixed results. Those mixed results were a combination of getting the OpenLDAP service to start from the command line (after tweaking some command line arguments to the "slapd" exe by adding a reference to the config file) to the service no longer starting thereafter. When the service would no longer start, I got the dreaded "slapd starting" message in the console whereupon the service would do little else. According to Google searches, the solution appeared to be to "download a later version of OpenLDAP" which clearly wasn't an option as I needed to use the Oracle implementation of OpenLDAP.

At this point I figured that a re-install was probably on the cards so I uninstalled EPM, deleted the directory into which it had been installed and then reinstalled the EPM software. Guess what... The OpenLDAP service started! oooOOOOOooooo. So a quick config of the services and... D'OH! still no joy! None of the services were able to register with Shared Services. Grumble, grumble, grumble. What now?

Even more debugging and looking at the Shared Service log files showed messages such as "Native Directory is not reachable. Attempting to re-connect" with references to the server's hostname and a port number of 28089. This seemed to indicate that services were attempting to connect to OpenLDAP on port 28089 and couldn't get through. Further investigations showed that OpenLDAP does not use that port number by default, so it needs to be set at startup.

Now that's where the fun and games started. Rather than go through all the possible places where they can be set depending on which article you read (which I unfortunately tried), I'll just tell you the right place. It would appear (and I'm guessing here) that the installation of EPM on Windows Server 2008 does not install some much needed registry entries. A colleague of mine installed EPM on Windows XP and it all went well. A quick check of the registry on that machine confirmed that this is what was missing. So...

What you need to do, is to ensure that the following registry entries (and structure) exists in the registry:

[HKEY_LOCAL_MACHINE\SOFTWARE\OpenLDAP\Parameters]

with keys:

ConfigFile PathToOpenLDAPDirectory\slapd.conf
DebugLevel 0
Urls ldap://:28089

Note that the "ConfigFile" and "Urls" parameters are String settings whereas "DebugLevel" is a DWORD32

And that's it. A restart of the OpenLDAP service and Shared Services service meant that I could register all the other Hyperion services. The "Urls" parameter is the main setting, as that dictates that OpenLDAP is to listen on port 28089 which is what is required by the rest of the Hyperion services.

It may also be worth noting that a quick glance at the default slapd.conf file supplied by Oracle lists that a "pid" file and "arg" file be created in the ".../var/run" directory. Clearly a *nix setting but rather amusingly there is no "run" directory under the "var" directory in the Windows structure. If you create it, those files will be created. Also, it may well be worth you adding in an entry for the creation of a logfile. I added an entry in the "slapd.conf" file, immediately below the entries for the "run" and "arg" files to do this. The key looks like:

logfile PathToOpenLDAPDirectory\logs\slapd.log

To get logging to appear in this file you will need to change the value in the registry entry "DebugLevel" created earlier to a value other than zero. The number 4 is probably a good value to go for or 1 if you wish to debug issues.

And there you have it. I hope that this helps others to have more time to do things other than the configuration of EPM.

Good luck.

The ProClarity API - Programmatic changes to ProClarity briefing books

We have a client who is using Analysis Services 2000 and ProClarity Analytics Server 6.3 in order to provide balance sheet and financial line information to their business. The system that I designed had to be able to aggregate financial data up a customer hierarchy but be able to aggregate the data into parents as they stood at the time the data was loaded and against the current parent. (i.e. A slowly changing dimension.) However, this dimension consists of over 1.5 million members and there are effectively two versions of this in the database.

Now this on its own is fine-ish, in that with the 3GB switch enabled and some tweaks to the cleaner thread interval the AS solution is stable and performs reasonably well. However, the original requirement did not specify security on these dimensions. As you can guess, there is now a requirement to place security on these dimensions, partially to limit access to the data but more so to provide a way for a given user's reports to open, defaulted to the customers for which they are responsible.

Now trying to add security using a "security cube" isn't really conducive to performance and adding 440 roles to AS, each with a different security context, isn't really good for maintenance or memory. (i.e. Think replica dimensions.) So, what else?

Well, as an approach, I wondered if it is possible to take a template ProClarity briefing book located in a PAS Store, load it and customise it for a given user and write it back to the PAS store. From previous experiences I know that just updating the XML in the PAS database for a given briefing book and pages causes problems down the line, to the point that they may no longer work. So how else? Can you make programmatic changes? I know that there is an API for ProClarity but the documentation is all for VB etc. and not .Net.

In the end I decided to give it a try and started to write an application that would retrieve a result set from a database specifying the template book and pages etc. that are to be customised and the customisations to be made. It also specifies the PAS store into which the book should be ultimately published and security assignments for the new book.

After contacting Microsoft on TechNet for some hints and tips (whose responses are pretty quick and impressive actually) I was on my way. See Hints and Tips for that thread.

The essentials to know, when using C#, are effectively as follows:

1. In order to have a briefing book loaded within a ProClarity application in memory, use the KProClarityClass.StartupBook method.
2. Once you have a KProClarityClass object, use the following objects, properties or methods as shown below...

   Application (Object)
   |
   CurrentView (Property)
   |
   PageCtrl (Object)
   |
   KPCommand (Object)
   |
   GetAxisMemberSet (Method)
   |
   KMemberSet

   As an example, use the KProClarityClass's Application property to retrieve a reference to the Application object. Now use the Application object's CurrentView property to retrieve a reference to the the ICurrentView interface etc. etc.

3. If you make any changes to a KMemberSet, you must use that object's associated KCommand object's execute method in order update all associated entities within the ProClarity object model.
4. If you copy elements etc. be sure to update the copied element's ID otherwise you will get errors when trying to publish the briefing book. (i.e. You will have two elements with the same ID which understandably is not allowed.) To do this, set the ID for the given element to: "{00000000-0000-0000-0000-000000000000}"
5. In order to commit changes you have made to a given briefing book page, you have to copy the "page" within the book, using the CurrentView's AddPageToBook method and then delete the original page. Please don't shout at me, I know, that sucks but that's just how it is okay?


In the end I changed my application to run as a custom SSIS task and to be multi-threaded using a blocking-queue in order to hand out template briefing books for updates to consumer threads etc. That all seemed to work although I did experience exceptions when running the task in debug mode. As can be seen by the following thread with Microsoft here, this was related to my code not being aware of the COM aspects of the ProClarity API.

All in all it was quite fun to develop, creating mini-caches for PStore connections etc. and to implement a solution that runs within SSIS. I added in the ability to set properties such as the number of threads to use and the ability to set the table and column names that store the relevant updates to be made.

Using simple test cases it appears to work quite nicely. Reports remain static, such that reports with both grids, totals and graphs etc. retain that layout when the member selections are changed. The task allows the ability to either update members by axis or to simply replace the MDX for the report. (Actually you could replace the MDX for a report and then customise the member selection immediately thereafter if you so wished but why?)

Before it's a finished beta v0.0.0.0.0.0.1 "product" (Oracle style versioning there) the task needs to accommodate pages within nested folders (i.e. currently only handles pages at the root or one level below) and to complete the security aspect. I also need to normalise the table structures that store the updates to be made against the template briefing book etc.

Anyhoo, if anyone out there is interested in using this please add a comment to this blog and I'll see if I can add it to our company's website for download. That naturally assumes anyone actually reads my blog...

Oracle 11g on Oracle Linux

Intro
So here's the thing...

I decided to have a more detailed look at Oracle 11g. I like the Oracle relational databases, really I do. They are a mature, stable, scalable database which is feature rich. It can run on Linux, Unix, Windows and even a Mac if you want. However, my focus in this blog is the installation of the database on Linux. Oracle's own in fact...

So Oracle offer a "distro" of Linux. Sounds good as a concept, Oracle offering an OS on which you can install their database and all. However, if you are a newbie to Linux and/or Oracle you gonna need to set aside quite a bit of time for this. (By quite a bit, read: "a lot!")

Now my issue isn't so much the number of settings required during installation, it's a complex piece of software, nor the planning on how it should be or where it should be installed. All that is fine. I understand that. It's just that the actual act of installing Oracle 11g on Oracle Linux should be, well, seamless should it not?

Grumbles
I'm sorry, the fact that I installed Oracle linux with practically all package options selected (didn't select the KDE development ones) yet still didn't get the "oracleasm" packages installed mystifies me. The fact that I didn't get prompted with a question asking "are you intending to use this installation as a platform for another Oracle product" and then providing me with a list, is a little concerning. Some way of being able to configure the installation of the OS based on what I want to do later with other Oracle products seems somewhat natural, yet it is lacking. But what really sends me down a rabbit hole of despair, is the fact that of the 3 "oracleasm" packages required for using Automated Storage Management, one of them is not included in any of the 5 disks of Oracle Enterprise 5 ISO images.

I cannot help but wonder if I am just being picky. It's just that it seems natural to me to include all requirements for a successful installation in the installation software. In order to use ASM I need to have already installed the ASM libraries, yet to do that I need to go to OTN and download the missing package. To make matters worse, the package seems to have been released a long time ago yet the ISO images for Oracle Linux Enterprise 5 have not been updated to include them.

Then, to top it all off, once you actually get the dang thing installed, (i.e. the OS and 11g) there are no installations of start up scripts or anything. Nope. Nada, bupkiss, didley-squat! You want Oracle 11g to start up automatically you darn well get to write them yourself or find someone else's on the web and use that. As it happens, using someone else's is probably natural seeing as by the time you've actually managed to install the software you are probably on to your 2nd or 3rd blog, the writers of which have probably included theirs.

Add to this that if you are using ASM without RAC, you need to include the marking of your RAW disks for oracle ASM in your start up scripts in order to get the ASM service to know about else the Oracle database won't start. (Maybe this is meant to be included in a config file somewhere but I couldn't find any documentation on that. Some blogs talk about using "rawdevices" but that has been deprecated now.)

Finally
The long and short of all of this is that I can fully understand now, why someone would install Microsoft SQL Server for a demo etc. You could have Windows installed, the SQL Server software installed and configured and the demo built whilst you are still faffing about trying to get everything you need for the Oracle installation.

What a shame... In my opinion, for what its worth, the Oracle RDBMS is far better and complete in its offering than SQL Server. I guess I mean it is more mature. But lets face it, money talks, and if at a fraction of the price you can have a database and have it installed dancing on one leg whistling Dixie in the fraction of the time of something else, why wouldn't you?

Links I used:

1. Install Oracle 11g for RAC
2. Create RAW devices using LVM
